产品系列
B0801
端接类型
SMT
连接器类别
板对板连接器
型式
Female
间距
0.80mm
排数
双排
pin数
50Pin
角度
180°
胶芯颜色
黑色
端子电镀
G/F
环保性质
RoHS+HF
胶芯材质
PA9T,UL94V-0
产品类型
连接器
端子材质
Phosphor Copper
额定电流
0.5A
额定电压
60V
绝缘电阻
800MΩ Min
接触电阻
60mΩ Max
耐电压
500V AC
耐温
260℃
盐雾
24H
工作温度
-25℃~+85℃
湿气敏感性等级MSD
LEVEL 1
拔出力
0.06kgf/Pin Min
插入力
0.12kgf/Pin Max
保持力
0.12kgf/Pin Min
耐久性
30cycles
Pitch 0.8mm BTB、满足电子设备电源传输要求、满足产品小型化、多P位化需求、满足高速传输需求;产品适用于电源、显示屏、电脑、办公设备、通讯等设备等电子产品。
